Why Your Brother PE770 Bobbin Thread Won’t Catch (and How to Fix It)

When your embroidery machine suddenly stops picking up bobbin thread, it can feel like the end of the world (or at least the end of your project 😅). The Brother PE770 is a solid machine, but like any embroidery model, it has a few weak spots that show up after heavy use. Let’s break down the common causes and fixes.


First Quick Checks

  • Needle orientation: Even if you’ve replaced it, double-check that the flat side is facing the correct direction and fully inserted. A needle that’s even slightly off won’t catch the bobbin loop.

  • Correct bobbin type: PE770 requires SA156 bobbins (class 15 plastic). Using the wrong size or a cheap aftermarket bobbin can cause the hook to miss the thread.

  • Upper threading path: Rethread the top with the presser foot up so the thread properly seats into the tension disks.


🛠 Inside the Bobbin Area

  • Lint & debris: You said you cleaned, but go deeper — remove the bobbin case and clean around the hook race with a brush and canned air. A single dust bunny can stop the hook from grabbing the thread.

  • Bobbin tension screw: If your bobbin screw was adjusted before (less than 90° clockwise), it may now be too loose/tight. Reset it to factory spec if possible.


Timing & Hook Issues

Since you mentioned 332,945 stitches since your last service, it’s worth noting:

  • Hook timing may be off. The needle should descend, and just as it begins to rise, the hook should pass right behind the eye. If that alignment slips (common after lots of stitches), no amount of rethreading will fix it — it needs adjustment.

  • Upper tension at -2 is unusual. If the last service tech “compensated” with tension instead of resetting timing, you may be seeing the result now.


👩‍🔧 When DIY Isn’t Enough

If you’ve tried new needles, proper threading, cleaning, and correct bobbin type but still no luck, the problem is likely timing drift or hook wear. These require professional service — and at ~330k stitches, your PE770 is due for one anyway.

💡 Expert tip: Many owners report that servicing every ~200–250k stitches helps avoid these sudden failures.


Brother PE770 Not Catching Bobbin Thread: Troubleshooting Guide

📌 Pro Tips to Remember

  • Always thread with the presser foot up.

  • Replace needles every 8–10 hours of stitching.

  • Stick to genuine Brother bobbins & needles.

  • Keep a log of stitch count since last service.


Final Word

Don’t panic — this is a very common issue on the PE770 after heavy use. If the basics don’t solve it, a timing reset at your local Brother tech will get you stitching again quickly.
